Features of the device:
1. Automatic feed, quick and accurate, save manpower.
2. The special designed feed mechanism is accurate and reliable, and the intermediate transport station can choose the type of the necessary type according to the outer diameter of the pipe.
3. Strong head design, power head and motor drive, head fixed. Growth knife life.
4. Use self-centering fixture to ensure the processing concentricity.
5. With the speed of double speed of the shock absorber, it saves working hours, and is easy and easy to adjust and perfect.
6. The whole process touch screen controls PLC, pneumatic automatic control, pneumatic clamping, pneumatic feed, simple and convenient operation.
7. The system is manual, automatic and easy to debug and use.
8. End special cutter design, using normalized blade, adjust the knife is simple and convenient, the tube Angle, corner, surface finish in one time, an average of 3 to 10 seconds a (according to the size of the pipe diameter and thickness), fast efficiency.
9. The guide rail in the head of the machine adopts the casting, which improves the precision by grinding the grinding machine.
- Model CLD-50A-QB
Host motor 2HP/4P*2
Pipe diameter ¢6mm- ¢ 50mm
Short pipe length 30mm-110mm
Long pipe length 110mm-550mm
Cutterhead Standard cutterhead
Blade Tungsten carbide throw-away blade
Hydraulic pump 0.75KW/20 Lite pump work pressure20-30KG/CM2
Standard fittings 1.one set clamps 2.one set cutter and one set blade
Special fittings 1.clamps of different sizes 2.special cutterhead 3.Automatic feeding system
Machine weight 680kg
Machine Dimension 1800mm×1000mm×1100mm
