Model |
HT25 |
|
Weight |
2500kg |
|
Product |
2.5ton Crawler Mini excavator |
|
Bucket capacity |
2.6CBM |
|
Standard bucket width |
490mm |
|
Engine model |
KUBOTA ENGINE or LAIDONG Engine |
|
Rated power |
20kw/2200rpm |
|
Displacement |
1.813L |
|
Cylinders |
3 cylinder, water cooled |
|
Bore X Stroke |
90 X 95mm |
|
Main pump |
Triple cylinder |
|
Rated Pressure |
25/31.5 MPA |
|
Fuel Tank Capacity |
40L |
|
Hydraulic oil tank |
60L |
|
Overall dimension( LxWxH) |
4130 X 1300 X 2280mm |
|
Track Gauge |
950 mm |
|
Counterweight ground clearance |
460mm |
|
Track grounding length |
1250 mm |
|
Total track length |
1610 mm |
|
Track show width |
230 mm |
|
Total Track width |
1200mm |
|
Min ground clearance |
190 mm |
|
Booming swing angle |
70(lh)/50(rh) |
|
Grade ability |
30° |
|
Slewing angle |
360° |
|
Travel speed |
2.2 km/h |
|
Max digging height |
3714mm |
|
Max digging radius |
4023mm |
|
Max digging depth |
2150mm |
|
Max dumping height |
2488mm |
